RaidBox

HP S700 500GB SATA 6Gb/s

$96.99
  • HP S700 500GB SATA 6Gb/s

RaidBox

HP S700 500GB SATA 6Gb/s

$96.99
Information
HP SSD S700 Series delivers compact storage and optimized performance for traditional and innovative small-form-factor and embedded platforms.

The case 2.5inch SSD design has a significantly smaller footprint than a 2.5inch hard disk drive (HDD), and enables fast read/write access times and a significant I/O and throughput performance improvement as compared to HDDs. This design makes it ideal for new and innovative small form factor computing platforms that have size and weight requirements that traditional 2.5inch HDD s cannot meet; such as, notebook, thin-and-light systems, mini-and sub-notebooks, all in-one computers, and embedded platforms.

features
• High performance
• Low power
• Increased system responsiveness
• High reliability
• Small form-factor
• Minimum weight
• Enhanced ruggedness
Capacity:
500GB
Components:
3D TLC NAND Flash
Read and Write IOPS
Random 4 KB reads: Up to 55 K IOPS
Random 4 KB writes: Up to 80 K IOPS
Bandwidth Performance
Sustained sequential read: Up to 560 MB/s
Sustained sequential write: Up to 515MB/s
SATA 1.5 Gb/s ,3 Gb/s and 6 Gb/s interface
ATA/ATAPI-7
SSD-enhanced S.M.A.R.T. ATA feature
Native Command Queuing (NCQ) command set
Data set management command Trim attribute
Form Factor
Full-sized 2.5inch SSD
Power Management
5 V 2.5inch SSD power supply
2.5inch SSD interface power management
Power (Mobile Mark 2007 Workload)
Idle: 340 mW(TYP)
max: 1.38W (TYP)
Temperature
Operating: 0oC to 70oC
Non-Operating: -40oC to 85oC
Shock (operating and non-operating)
100 G/6 msec
Vibration(operating and non-operating)
3.1G RMS (2-500 Hz)
Latency
Read: 0.030ms (TYP)
Write: 0.174ms (TYP)
Reliability
Uncorrectable Bit Error Rate (UBER): 1 sector in 1016bits read
Mean Time Between Failures (MTBF): 2,000,000 hours
Certifications and Declarations
UL
CE
FCC
RoHS
